Dimmer DALI SUNRICHER 8-46v (SRP-TRIAC-24-30CV)

1 176.00 דנם.

Price per 1 רע

in stock

Product code: 42041

Converting the DALI control signal to PWM. The output current is adjustable from 200mA to 1500mA using DIP switches on the driver, which allows it to be used for LED lamps of various currents. Output power from 11W to 30W (depending on the set output current). Output voltage 24 VDC. Power factor PF >0.9, efficiency >83%. Smooth and deep dimming up to 0.1% without flicker and noise. 1 The DALI address can be automatically assigned by DALI master controllers. According to IEC62386-101, 102, 207, this DALI driver is compatible with universal DALI controllers. There is an error reporting function. Size: 534x170x28mm.

Guarantee

36 לוס�צוג from manufacturer
exchange / return of goods within 14 days

Payment:

cash on delivery
Payment to account
cash to courier (Kharkiv only)

Delivery:

in Ukraine by carriers
pickup from warehouse (Kharkiv only)
by courier in Kharkov

Description

The output current is adjustable from 200mA to 1500mA using DIP switches on the driver, which allows it to be used for LED lamps of various currents. Output power from 11W to 30W (depending on the set output current). Output voltage 24 VDC. Power factor PF >0.9, efficiency >83%. Smooth and deep dimming up to 0.1% without flicker and noise. 1 The DALI address can be automatically assigned by DALI master controllers. According to IEC62386-101, 102, 207, this DALI driver is compatible with universal DALI controllers. There is an error reporting function.

Technical specifications

Manufacturer:	SUNRICHER
Cabinet dimensions (L x W x H):	534 x 170 x 28 mm
Operating voltage:	220V
Output voltage:	8-46V
Output current:	from 200mA to 1500mA
Output power:	from 11W to 30W
Control type:	DALI
Number of channels:	1 channel
Number of zones:	1 zone

* Product specifications and packaging may be changed by the manufacturer without notice
